Why us…..
Our machine shops offers a wide variety of machines and extremely skilled and experienced associates to meet your demanding requirements of accuracy along with low lead times.
The most trusted and reliable suppliers of machined graphite components from India.
Properties of graphite that we offer.
| Specifications | Unit | ISOSTATIC GRAPHITE | VIBRATED GRAPHITE | ||||
|---|---|---|---|---|---|---|---|
| EM | GEH-1 | GEH-2 | GEH-3 | GEH-4 | |||
| Bulk Density | g/cm3 | 1.82 | 1.85 | 1.82 | 1.83 | 1.92 | 1.72 |
| Avg. Grain Size | μm | 14 | 12 | 10 | 7 | 4 | 0.8 mm |
| Specific Resistance | μΩ.m | 9 | 10 | 13 | 17 | 10 | 9 |
| Flexural Strength | Mpa | 46 | 50 | 62 | 64 | 64 | 17 |
| Compressive Strength | Mpa | 90 | 98 | 113 | 117 | 127 | 32 |
| Shore Hardness | 48 | 65 | 62 | 72 | 68 | 35 | |
| Thermal conductivity | W/mk | 140 | 85 | 104 | 81 | 128 | >120 |
| Ash Content | (500 PPM) | (500 PPM) | (300 PPM) | (300 PPM) | (300 PPM) | (500 PPM) | |
